Page #121 background image

Loading...

Page #121 background image

12. BODY COVER

12-12

Note:

This chapter Contents

Table of Contents

Questions and Answers:

J
Joan RodriguezJul 31, 2025
Why is my Sym Scooter engine hard to start?
- A
  Aaron JacksonAug 1, 2025
  If your Sym Scooter engine is hard to start, there might be several reasons. It could be due to no fuel in the fuel tank, in which case you should check and adjust the fuel level. Another possibility is a clog in the pipes, fuel tank, carburetor, or intake vacuum, so inspect these components for blockages. A malfunction or loosen/damaged fuel pump vacuum could also be the culprit, requiring a check and adjustment. Additionally, try loosening the carburetor drain bolt to check for gasoline inside the carburetor, or remove the spark plug, install it into the spark plug cap, and perform a spark test against the engine ground.
D
Darin JacksonAug 8, 2025
What to do if Sym Jet 50 Scooter engine runs sluggish and speed doesn't pick up?
- M
  Mr. Elijah Hensley IVAug 9, 2025
  If your Sym Scooter engine runs sluggish and the speed doesn't pick up, it could be due to several reasons. The air cleaner might be clogged, so check the ignition timing using an ignition lamp. Poor fuel supply could also be the issue; try gradual acceleration and check the engine speed. You should also check the cylinder compression pressure using a compression pressure gauge and inspect the carburetor for any clogs. Lastly, verify if the engine is overheating.
D
Dale PriceAug 15, 2025
Why Sym Scooter engine runs sluggish at high speed?
- V
  vgoodwinAug 15, 2025
  If your Sym Scooter engine runs sluggish specifically at high speed, check the ignition timing. Also, if there is insufficient fuel in the fuel tank, a fuel filter clogged, or a restricted fuel tank vent, you should check the fuel supplying system in the automatic fuel cup. Furthermore, check if the carburetor is clogged.

Sym Jet 50 Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Top Speed	45 km/h
Displacement	49.5 cc
Cooling System	Air
Transmission	CVT

Summary

General Information

Symbols and Marks

Explains symbols and marks used for service information and procedures.

General Safety Precautions

Details safety precautions for operating and servicing the motorcycle.

Specifications Overview

Lists technical specifications for JET 50/100 series motorcycles.

Troubleshooting Engine Issues

Provides guidance for diagnosing and resolving engine starting and running issues.

Service Maintenance Information

Periodical Maintenance Schedule

Outlines recommended maintenance intervals and tasks for the scooter.

Tire Maintenance

Covers tire inspection, recommended pressure, and wear limits.

Battery Service

Details battery removal, installation, and voltage checks.

Spark Plug Service

Explains spark plug inspection, gap measurement, and replacement.

Fuel System Maintenance

Fuel System Precautions and Troubleshooting

Covers precautions, specifications, and troubleshooting for the fuel system.

Throttle Valve Assembly Service

Details the removal, inspection, and installation of the throttle valve assembly.

Fuel Pump Service

Explains fuel pump inspection, output measurement, and removal/installation.

Air Cleaner Maintenance

Covers the removal and installation procedure for the air cleaner.

Brake System Service

Brake System Precautions and Specifications

Includes safety precautions, specifications, and torque values for brake systems.

Brake System Troubleshooting

Lists common brake system issues and their probable causes for disc and drum brakes.

Hydraulic Disc Brake Fluid Service

Outlines the procedure for changing brake fluid and bleeding the system.

Drum Brake Inspection and Removal

Details the inspection and removal of brake linings and drums.

Electrical Equipment Maintenance

Electrical System Precautions and Specifications

Provides precautions and specifications for charging and ignition systems.

Electrical System Troubleshooting

Covers common electrical system issues like no voltage, low voltage, and starter problems.

Battery Service and Charging

Explains battery removal, installation, voltage checks, and charging procedures.

Ignition System Service

Includes wiring diagrams and inspection procedures for the ignition coil.

Electrical Diagrams

JET 50 Electrical Diagram

Provides the complete electrical wiring diagram for the JET 50 model.

JET 50 EURO Electrical Diagram

Presents the electrical wiring diagram for the JET 50 EURO model.

JET 100 Electrical Diagram

Shows the electrical wiring diagram for the JET 100 model.
