7. “V” TYPE BELT DRIVE SYSTEM/KICK-STARTER
7-1
Maintenance Information ················ 7-2
Trouble Shooting ····························· 7-2
Left Crankcase Cover······················ 7-3
Reassembly Of Kick Starter············ 7-4
Installation Of The Left Crankcase
Cover················································· 7-4
Drive Belt···········································7-5
Movable Driven Pulley ·····················7-6
Clutch/Driven Pulley·························7-10
7
3.8 kg
-m
3.8 kg
-m
5.5 kg
-m
