3. LUBRICATION SYSTEM
3-5
Oil Tank
Removal/Installation
Remove the luggage box and seat.
Remove the battery and battery box.
Remove the R/L. side cover, rear center cover,
rear carrier and body cover.
Remove the rear fender.
Remove the oil input tube from oil pump, and
then drain oil to a clean container.
Remove the oil switch wire of the oil indicator.
Remove the mounting bolt on the oil tank upper
side, and then remove the oil tank.
Installation in the reverse order of removal.
Air bleeding the oil tubes after installation.
Blot ×2
Screw ×2
Blot ×1
Mounting bolt
