SYM 10. A.C. GENERATOR/STARTING CLUTCH
10-1
PRECAUTIONS IN OPERATION .......10-1
A.C.GENERATOR REMOVAL............10-2
RIGHT CRANKCASE COVER REMOVAL .10-3
RIGHT CRANKCASE COVER INSTALLATION ...10-4
MOUNTED COIL SET INSTALLATION
........10-4
FLY WHEEL INSTALLATION.............10-4
PRECAUTIONS IN OPERATION
General information
 Refer to chapter 5: Engine removal and installation
 Refer to chapter 1: The troubleshooting and inspection of A.C. generator
Specification Unit: mm
Item Service Limit
ID of starting driven gear 32.060
OD of starting clutch cover 27.940
Torque value:
Flywheel nut 3.5~4.5kgf-m
Exhaust muffler bolt 6 mm 0.7~1.1kgf-m
Oil screen cover 1.3~1.7kgf-m
Special service tools
Flywheel puller
Universal fixture

Sym Orbit 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Wheelbase	1280 mm
Headlamp	Halogen
Engine Type	4-Stroke, Single Cylinder
Starting Method	Kick start
