SYM 13. BRAKE
13-1
MECHANISM DIAGRAM-FRONT DISC BRAKE SYSTEM.....13-1
MECHANISM DIAGRAM-FRONT DRUM BRAKE SYSTEM .13-2
MECHANISM DIAGRAM-REAR DRUM BRAKE SYSTEM ..13-3
MAINTENANCE INFORMATION.......13-4
TROUBLE DIAGNOSIS .....................13-5
HYDRAULIC BRAKE SYSTEM INSPECTION.....13-6
BRAKE FLUID REPLACEMENT/AIR-BLEED .....13-7
BRAKE CALIPER.............................. 13-8
BRAKE DISC ..................................... 13-9
BRAKE MASTER CYLINDER ........... 13-9
DRUM BRAKE-DRUM....................... 13-12
BRAKE LING..................................... 13-12
BRAKE PANEL.................................. 13-13
MECHANISM DIAGRAM
Front Disc Brake System
11.0~13.0 kgf-m
4.0~4.5 kgf-m
0.8~1.0 kgf-m
3.3~3.7 kgf-m
2.8~3.2 kgf-m

Sym Orbit 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Wheelbase	1280 mm
Headlamp	Halogen
Engine Type	4-Stroke, Single Cylinder
Starting Method	Kick start
