SYM 13. BRAKE
13-3
MECHANISM DIAGRAM
Rear Drum Brake System
0.8~1.2 kgf-m
0.8~1.2 kgf-m

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sym Orbit 125 and is the answer not in the manual?

Sym Orbit 125 Specifications

General IconGeneral
Displacement124.6 cc
Front SuspensionTelescopic Fork
Front BrakeDisc
Rear BrakeDrum
Wheelbase1280 mm
HeadlampHalogen
Engine Type4-Stroke, Single Cylinder
Starting MethodKick start
