Sym Orbit 125 - STEERING, FRONT WHEEL, AND FRONT SHOCK ABSORBER; MECHANISM DIAGRAM

SYM 14. STEERING/FRONT WHEEL/FRONT SHOCK ABSORBER
14-1
MECHANISM DIAGRAM ....................14-1
PRECAUTIONS IN OPERATION .......14-2
TROUBLE DIAGNOSIS......................14-2
STEERING HANDLE..........................14-3
FRONT WHEEL .................................14-4
FRONT SHOCK ABSORBER............. 14-9
FRONT FORK/STEERING COLUMN 14-9
MECHANISM DIAGRAM
3.1~3.5kgf-m
1.0~2.0kgf-m
5.0~7.0kgf-m
0.2~0.3kgf-m
4.0~5.0kgf-m
11.0~13.0kgf-m
2.4~3.0kgf-m
