Description
|
7
5.2.3 Types & variants
Table 3 Axial fan base types
Type
Description
AXC
Standard fan of the AXC-series. As a default, the fans are provided in protection class IP55,
ISO F.
AXS
Special fans for marine, oil and gas applications.
AXR
The conveying direction can be reversed by switching the direction of rotation.
Table 4 Axial fan variants
Type
Description
-P
Fan of AXC-series which uses impeller design of the "-P" generation.
-PV
Fan of AXC-series which uses impeller design of the "-P" generation and has a bolted-on
guide vane.
-Box
Fan of AXC-series inside a sound-insulated box.
-G
Fans constructed as garage version. Arrangement of two fans in series, switched behind
one another.
(B)
Smoke extract fan suitable for 2 hours at 300°C. As a default, the fans are provided in
protection class IP54/55, ISO H. The connection wire from the motor to the terminal box is
protected via an additional flexible metal hose. The standard motors (400 V type B3) are
without motor protection.
(F)
Smoke extract fan suitable for 2 hours at 400°C. As a default, the fans are provided in
protection class IP54/55, ISO H. The connection wire from the motor to the terminal box is
protected via an additional flexible metal hose. The standard motors (400 V type B3) are
without motor protection.
-SC
Short Casing.
-H
High pressure fan
