SystemAir AXS Series User Manual

Description
|
13
5.4.1 Construction
1 Motor
1
2
3
4
2
Impeller
3 Housing
4 Motor
bracket
Table 7 Dimensions
Size 250 — 500 Size 630 — 800
F
½I
I
H
A
B
D
C
F
D
C
A
½I
I
H
Size
[mm]
A
Ø B Ø C Ø D Ø F Ø H
I
AXCBF 250 535 448 328 250 280 10 8x45°
AXCBF 315 535 452 385 320 355 10 8x45°
AXCBF 400 625 585 480 400 450 10 8x45°
AXCBF 500 660 695 590 500 560 12 12x30°
AXCBF 630 790
—
634 630 690 12 12x30°
AXCBF 800 880
—
797 800 860 12 16x22.5°
| 014
