Description
5 Description
5.1 General
• The fan conveys air in an axial direction from the intake side via the electric motor to the outlet side. (except AXCBF).
• The electrical connection is made through a terminal box installed on the outside of the housing (except AXCBF).
Sensors (optional)
Sensors can be connected to the fan to monitor the roller bearings and for vibration monitoring.
Standstill heating (optional)
The standstill heating starts when the motor switches off and vice versa.
5.1.1 Fan and motor data
• The technical data of the fan can be seen on the name plate or the data sheet.
• The motor data can be found on the name plate of the motor or in the technical documents of the motor
manufacturer.
• The data on the name plate of the fan apply to "standard air" according to ISO 5801.
5.1.2 Temperature types
Table 2 Types of fans
Type
Diameter
[mm]
Long-term
operation
–20°C...55°C
Long-term
operation
-20°C...200°C
(B) 300°C/
120 min.
(F) 400°C/
120 min.
AXC
1
/AXR/AXS
315 — 1600 X
AXCBF 250— 800 X X
AXC (B)
1
/AXR (B)
315 — 1600 X X
AXC (F)
1
AXR (F)
315 — 1600 X X
AJR/AJ8
315 — 400 X
AJR (B)/AJ8 (B)
315 — 400 X X
AJR (F)/AJ8 (F)
315 — 400 X X
1
also —P, —PV,—H and —G
| 014
