| Name plate and type key
5.5 Intended use
All axial fans
• The temperature of the air transported through the fan must not exceed the temperature range stated on the
name plate.
• For the temperature resistance of the smoke extraction fans (K), (B), (F), which can also be used to extract CO,
please refer to the name plate (e.g. 300°C/120 min).
Jet fans
• AJ8 and AJR jet fans are intended for installation in
underground and above-ground parking structures, to
facilitate ventilation and smoke extraction.
• For optimum operation, the jet fan must be
suspended horizontally from the ceiling in such a
position that intake and outlet are unobstructed.
Axial fans
• The axial fans of the series AXC/AXR/AXCBF in the
versions G (K), (B), (F) are intended for installation in
ventilation systems.
• The axial fans of the series AXC/AXR/AXCBF are
ready-to-use products and are used as components
for ventilation devices, machines and systems. These
fans can be used to extract, draw in or convey air.
• The fans can be installed both in duct systems and
also with free suction via an inlet cone and a suction-
side contact protection grille. Free discharge via a
contact protection grille is also possible.
Incorrect use
Incorrect use refers mainly to using the fan in another way to that described. The following examples are incorrect and
hazardous:
• The fan is not suitable for intake of aggressive media or media with a dust content so high that dust deposits on the
impeller or fan housing can affect the operation of the fan.
• The fan must not be installed in hazardous areas (areas with a potentially explosive atmosphere).
• The motors cannot be voltage controlled.
6 Name plate and type key
Values for the single fan unit at power efficiency optimum
determined without speed control
Installation and Operating Instructions are within the delivery.
Systemair GmbH - Seehöfer Straße 45 - 97944 Boxberg - Germany
* A variable speed drive must be installed with this fan!
P
1
:
0,92 kW
RPM:
2.940
Pitch angle:
20°
V:
3.218 m³/h
psf:
332 Pa
Number of certification:
This Powered Smoke and Heat Control ventilator shall be installed as per the manufacturer´s instruction.
Measurement cat. / Efficiency cat.:
A / Static
Efficiency grade:
(N38) N=39,0
Number of certification UK:
0086 CPR 719672
Max. temperature of transported air:
55°C - 300°C/2h
 :
32,4 %
Weight:
2797 CPR 719672
38 kg
H
Protection class, motor:
IP55
Fan impeller speed:
2865 1/min
Insulation class:
Nominal current:
1,66 A
Frequency:
50 Hz
Nominal power at shaft (P2):
0,75 kW IE3
Cosij
0,79
Voltage:
400V Y
Made in:
Germany
Manufacturing date:
06/2021
Order no. / Production no.:
0003500662 / 1251364
Type:
AXC 355-6/10°-2(B)-P
Stage 1 of 2
3
EN 12101-3 (2015)
Powered Smoke and Heat Control ventilator
1
2
3
4
5
6
1
General data
2
Technical data
3
Temp./Time information/
only listed on smoke
extraction fans
4
ErP data
5
Certifications and QR—
Codes
6
Manufacturer Address
