English
19SysAqua
11. WIRING DIAGRAM AND LEGEND
N 805
11.1. WIRING DIAGRAM
SEE APPENDIX
11.2. LEGEND
11.2.1. POWER SUPPLY
SE 4356 models 25 to 55: Control Mono 230V 50Hz +/- 10%
SE 4355 models 25 to 55: Power Tri 400V+N 50Hz +/- 10%
SE 4358 models 65 / 75: Control Mono 230V 50Hz +/- 10%
SE 4357 models 65 / 75: Power Tri 400V+N 50Hz +/- 10%
SE 4360 models 90 / 105 / 125: Control Mono 230V 50Hz +/- 10%
SE 4359 models 90 / 105 / 125: Power Tri 400V+N 50Hz +/- 10%
SE 4364 models 25 to 55 all seasons: Control Mono 230V 50Hz +/- 10%
SE 4363 models 25 to 55 all seasons: Power Tri 400V+N 50Hz +/- 10%
SE 4366 models 65 to 75 all seasons: Control Mono 230V 50Hz +/- 10%
SE 4365 models 65 to 75 all seasons: Power Tri 400V+N 50Hz +/- 10%
SE 4368 models 90 / 105 / 125 all seasons: Control Mono 230V 50Hz +/- 10%
SE 4367 models 90 / 105 / 125 all seasons: Power Tri 400V+N 50Hz +/- 10%
SE 4459 models 25 to 125 Soft Starter: Power Tri 400V+N 50Hz +/- 10%
SE 4568 models 90 / 105 / 125: Power Tri 400V 50Hz +/- 10%
SE 4570 models 25 à 55 all seasons: Power Tri 400V 50Hz +/- 10%
SE 4542 models 65 à 75 all seasons: Power Tri 400V 50Hz +/- 10%
SE 4491 models 90 / 105 / 125 all seasons: Power Tri 400V 50Hz +/- 10%
The supply is protected at the head by an FFG main fuse holder supplied by the installer. It must be tted
next to the unit. Refer to the § ELECTRIC SPECIFICATIONS, page 10
The electrical installation and wiring of this unit must comply with local electrical installation standards.
² Three phase 400 V~ 50Hz + Neutral + Ground :
On the L1, L2, L3, N terminals of the QG section switch
On the ground screw of the earth cable.
² Three phase 400 V~ 50Hz + Ground :
On the L1, L2, L3 terminals of the QG section switch
On the ground screw of the earth cable.
Power cable must be connected to the main power supply switch QG (Copper cable is recommended).
