21SysAqua
11.2.2.5. OPTION ALL SEASONS
FFOF1/2: fuse carrier
ACS1/2: three phase frequency variator of outside ventilation
KOF1 : three phase frequency variator command relay
FPC.AS : pressure transducer (high-pressure)
KA2 : auxiliary relay (reversible case)
11.2.2.6. OPTION SOFT STARTER
S.ST1/2: Soft Starter
K1/2: M1/2 compressors relay
MODELS 65 75 90 105 125
FTI
Range
24-32A 24-32A 37-50A 37-50A 48-65A
Adjustment
32A 32A 38A 46A 62A
FT2
Range
20-25A 24-32A 24-32A 24-32A 24-32A
Adjustment
22A 27A 32A 32A 32A
FTOF-L
Range (STD)
4-6.3A 4-6.3A 6-10A 6-10A 6-10A
Adjustment (STD)
4.4A 4.4A 7A 7A 7A
Range (HPF)
6-10A 6-10A 6-10A 6-10A 6-10A
Adjustment (HPF)
8A 8A 8.4A 8.4A 8.4A
FTOF-H
Range (STD)
4-6.3A 4-6.3A 6-10A 6-10A 6-10A
Adjustment (STD)
4.4A 4.4A 7A 7A 7A
Range (HPF)
6-10A 6-10A 6-10A 6-10A 6-10A
Adjustment (HPF)
8A 8A 8.4A 8.4A 8.4A
FTWP
Range
4-6.3A 4-6.3A 4-6.3A 4-6.3A 4-6.3A
Adjustment
4.9A 4.9A 4.9A 4.9A 4.9A
Contactors
KOF / KOF-L
KOF-H
STD
9A 9A 9A 9A 9A
HPF
9A 9A 9A 9A 9A
KWP1/2
6A 6A 6A 6A 6A
MODELS 25 30 35 40 45 55
FTI
Range
9-14A 9-14A 13-18A 13-18A 17-23A 17-23A
Adjustment
10A 11A 14.5A 15.5A 18A 22A
FT2
Range
9-14A 9-14A 13-18A 13-18A 17-23A 17-23A
Adjustment
10A 11A 14.5A 15.5A 18A 18A
FTOF-L
Range (STD)
1.6-2.5A 1.6-2.5A 1.6-2.5A 1.6-2.5A 2.5-4A 2.5-4A
Adjustment (STD)
1.8A 1.8A 2.2A 2.2A 3.5A 3.5A
Range (HPF)
4-6.3A 4-6.3A 4-6.3A 4-6.3A 4-6.3A 4-6.3A
Adjustment (HPF)
4A 4A 4A 4A 4.2A 4.2A
FTOF-H
Range (STD)
1.6-2.5A 1.6-2.5A 1.6-2.5A 1.6-2.5A 2.5-4A 2.5-4A
Adjustment (STD)
1.8A 1.8A 2.2A 2.2A 3.5A 3.5A
Range (HPF)
4-6.3A 4-6.3A 4-6.3A 4-6.3A 4-6.3A 4-6.3A
Adjustment (HPF)
4A 4A 4A 4A 4.2A 4.2A
FTWP
Range
1.6-2.5A 1.6-2.5A 2.5-4A 2.5-4A 2.5-4A 4-6.3A
Adjustment
1.8A 1.8A 2.6A 2.6A 2.6A 4.9A
Contactors
KOF / KOF-L
KOF-H
STD
6A 6A 6A 6A 6A 6A
HPF
6A 6A 6A 6A 6A 6A
KWP1/2
6A 6A 6A 6A 6A 6A
11.2.2.7. OPTION WITHOUT NEUTRAL
FF11: bipolar fuse carrier
T: transformer 400V/230V
11.2.3. RANGE AND SETTINGS OF THEMAL PROTECTION / NOMINAL INTENSITY OF THE CONTACTORS
(CLASSE AC3)
