SYSCROLL Air CO/HP 20 25 30 35
Rated voltage V/ph/Hz 400 ( ± 10%)/3+N/50
Max. absorbed power kW 10 12 13 16
Max. current FLA A 20 25 26 35
Max. start-up current LRA A 105 115 122 144
External fuses A 25 25 32 32
Max. cable section (*) mm
2
6 6 10 10
EXCHANGER RESISTANCE
Rated voltage V/ph/Hz 230 (±10%) / 1 / 50
Max. absorbed power W 70 90 90 90
8 - Technical Data
(*) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working
temperature in the room, the type of insulation and the cable laying, the maximum lenght of the power supply line.
8.3 Electrical data
Compressor electrical data
SYSCROLL Air CO/HP 20 25 30 35
Rated voltage V/ph/Hz 400 (± 10%) / 3 / 50
Number 1
Max. absorbed power kW 9 10 12 15
Rated current A 16 21 22 31
Oil pan resistor W 70 90 90 90
Pump electrical data
Fan electrical data
SYSCROLL Air CO/HP 20 25 30 35
Rated voltage V/ph/Hz 230 (± 10%) / 1 / 50
Number 2
Max. absorbed power kW 0,3+0,3
Absorbed rated current A 1,3+1,3
SYSCROLL Air CO/HP 20 25 30 35
Rated voltage V/ph/Hz 400 (± 10%) / 3 / 50
Number 1
Max. absorbed power kW 0,72
Absorbed rated current A 1,30
