SystemAir SYSCROLL 20-35 Air User Manual

36
75
10
250 1480
390
2005
1480
509
1360
60
26 457
26
60
9
P1P3
P2
P4
305 860
92
287
292
186
255
2501705
A
B
C
D
N
O
8.6 Dimensional Drawings - SYSCROLL 20-35 CO/HP + HYDROKIT
8 - Technical Data
Front view Side view
Top view
NOTE:
A Water inlet Ø1 1/4” FGM
B Water outlet Ø1 1/4” FGM
C Water charge ø 1/2” MGT
D Water drain ø 3/8” FGT
N Desuperheater water inlet ø1" FGM
O Desuperheater water outlet ø1" FGM

SystemAir SYSCROLL 20-35 Air Specifications

General

Brand	SystemAir
Model	SYSCROLL 20-35 Air
Category	Heat Pump
Language	English
