Tait T2010 User Manual

M2000-00 PCB Information 7.1
Copyright TEL 31/12/97
7 PCB Information
This Section provides parts lists, circuit diagrams and component location information
on the individual PCBs within the T2000 Series II radio.
The following PCBs are covered within this Section:
Section Title Page Frequency
(MHz)
7.1 T2000-100 RF PCB IPN 220-01331-02 7.1.1 220 to 270
7.2 T2000-200 RF PCB IPN 220-01202-10 7.2.1 66 to 88
7.3 T2000-300 RF PCB IPN 220-01314-01 7.3.1 136 to 174
7.4 T2000-400 RF PCB IPN 220-01204-11 7.4.1 175 to 225
7.5 T2000-500/-600 RF PCB IPN 220-01205-14 7.5.1 400 to 530
7.6 T2000-700/-900 RF PCB
IPN 220-01289-01
IPN 220-01389-03
7.6.1
7.6.11
330 to 400
7.7 T2000-800 RF PCB IPN 220-01305-03 7.7.1 800 to 870
7.8 T2000 IF PCB IPN 220-01384-00 7.8.1
7.9 T2000 TCXO/Tx Audio PCB
IPN 220-01389-00
IPN 220-01389-02
7.9.1
7.9.7
7.10 T2010 & T2015 HC05 Logic PCB IPN 220-01377-01
IPN 220-01377-02
IPN 220-01377-03
7.10.1
7.10.11
7.10.23
7.11 T2020, T203X, T2040, T2050 &
T2060 HC11 Logic PCB
IPN 220-01344-02
IPN 220-01344-04
7.11.1
7.11.13
7.12 T2010/T2030 Control Head PCB IPN 220-01319-01 7.12.1
7.13 T2015/T2060 Control Head PCB IPN 220-01320-01 7.13.1
7.14 T2020/40 /50 Control Head PCB IPN 220-01321-04 7.14.1
7.15 T2035 Control Head PCB IPN 220-01322-03 7.15.1
7.16 T2000 EMC Filter PCB IPN 220-01383-01 7.16.1
7.17 T2000 Data Interface Decoupling
PCB
IPN 220-01388-01 7.17.1
