M2000-00 T2000 EMC Filter PCB 7.16.1
Copyright TEL 31/12/97
Ref Var IPN Description Ref Var IPN Description
IPN 220-01383-01
C1 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C2 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C3 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C4 01 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C4 02 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C4 08 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C5 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C6 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C7 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C8 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C9 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C10 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C11 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C12 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C13 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C14 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C15 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C16 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C17 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C18 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
PDL-1 01 240-00026-31 CONN PADLE BRD 18WAY MICROMATCH
PDL-1 02 240-00026-31 CONN PADLE BRD 18WAY MICROMATCH
PDL-1 03 240-00026-31 CONN PADLE BRD 18WAY MICROMATCH
PDL-1 08 240-00026-23 CONN PADLE BD 8 WAY MICRO MATCH 0-215570-
SKT-1 01 240-10000-11 (L) CONN SMD SKT 18WAY MICROMATCH
SKT-1 02 240-10000-11 (L) CONN SMD SKT 18WAY MICROMATCH
SKT-1 03 240-10000-11 (L) CONN SMD SKT 18WAY MICROMATCH
SKT-1 08 240-10000-05 CONN SMD SKT 8WAY 2ROW MICROMATCH
02 205-00010-12 CABLE FLAT RBBN 16 CORE 16/7/0.1 GREY
08 205-00010-12 CABLE FLAT RBBN 16 CORE 16/7/0.1 GREY
220-01383-01 PCB T2000 SII EMC FILTER BRD
02 240-00020-56 PLUG 8WAY 2ROW(2X4) CORD MTG IDC MICROM
08 240-00020-56 PLUG 8WAY 2ROW(2X4) CORD MTG IDC MICROM
349-00020-32 SCREW TAPTITE M3X8MM PAN POZI BZ
Variants:
01 = T2020, T2035, T2040 & T2050 EMC radios
02 = Non-EMC remote mounted radios
03 = T2010, T2015 & T2030 radios
08 = Used in T2000-A03/-A04/-A16 remote kits (refer to Section 8.16)
7.16 T2000 EMC Filter PCB
T2000 EMC Filter Parts List (IPN 220-01383-01)
