31
29. Replacement Components
TASKI NO. INTELLIBOT SKU ITEM
7523968 049870 Filter - Cotton 10 Micron
7523969 1300165 Filter - Pleated 1 Micron
7523970 1300755 Filter - Cotton 20 Micron 10"
4132145 3300051 Front Blade - Squeegee - Linatex - SS
4132144 3300052 Rear Blade - Squeegee - Linatex - SS
4132108 1300027 Pad 15" Scrubbing Red
N/A 1300066 Pad 15" Scrubbing White
30. Storage
The following items should be taken into consideration when storing the robotic oor scrubbing system.
ENVIRONMENT
Temperature 59° to 86° F (15° to 30° C) operation, -22° to 140° F (-30° to 60° C) storage
Humidity 20% to 75% relative humidity
Attention
Never store the machine with discharged batteries. Otherwise, the batteries will be damaged beyond
repair. Be sure to fully charge batteries whenever storing the machine.
31. Troubleshooting
MALFUNCTION POSSIBLE CAUSES TROUBLESHOOTING
Machine without function
Charger plugged into robot • Unplug the charger
Battery pack not engaged • Push battery pack into place
Battery not charged • Load batteries
Leaving water
Water ow set too high
• Go to settings menu; lower water valve setting
default
Dirty squeegee
• Wipe squeegee with rag
• Flip or replace squeegee blade (can be
ipped up to 3 times before replacement)
Navigation issues
Sonar faulty • Perform sonar diagnostic, clean sonar
Mechanical drag • Inspect casters
Not cleaning oor surface Brush motor not running
• Reset circuit breaker
• Verify no obstacles are trapped in brush head
Machine pulling to one side when
manually driving
Parking brake is not fully
disengaged
• Move parking brake lever all the way to the
left, then all the way back to the right
If solution fails to correct the
problem
• Contact your service partner
