1-6
INTRODUCTION/SAFETY
Model C152 & C161
Introduction/Safety
1
Model C161 Specifications
Freezing Cylinder
Two, 1.5 qt. (1.4 L) volume.
Mix Hopper
Two, 8 qt. (7.6 L) capacity.
Beater Motor
Two, 0.5 hp.
Refrigeration Machine
One 3,500 BTU/hr compressor. R404A.
Separate Hopper Refrigeration (SHR), one 400 BTU/hr.
R134a.
(Actual BTUs will vary based on application.)
Electrical
Table 1-2
This machine may be manufactured in other electrical
characteristics. Refer to the local Taylor distributor for
availability. (For exact electrical information, always see
the data label of the machine.)
Air-Cooled
Clearance: 6 in. (152 mm) on left and right, and 0 in.
(0 mm) at the rear. Minimum air clearances must be met
to ensure adequate air flow for optimum performance.
Water-Cooled
Water inlet and drain connections out of rear 3/8 in.
(9.5 mm) FPT.
Dimensions
Width: 21 in. (533 mm)
Depth: 25-3/4 in. (654 mm)
Height: 29-3/8 in. (746 mm)
Counter Clearance: Designed to rest on a plastic pad
directly on the counter top or optional cart.
Approximate Weights
Note: For reference only, weights may vary depending
on accessories.
Net: 305 lb. (138.3 kg)
Crated: 350 lb. (158.8 kg)
Volume: 22.3 cu. ft. (0.63 cu. m)
Availability and specifications are subject to change
without notice.
This machine is designed and constructed to meet
stringent safety and sanitation requirements for NSF
and UL.
Electrical Total Amps
Supplied with
NEMA Cord
208/230/60/1 Air 12.0 6-15P
208/230/60/1 Water 12.0 6-15P
220-240/50/1 Air 10.0 ---
220-240/50/1 Water 10.0 ---
