Taylor C152 Service Manual

PARTS
4-19
Model C152 & C161
Parts
4
X59557-27 Box A.-Cap & Relay (Model C161)
Figure 4-13
* Not Shown
1 1 2 3
567898
9
4
4 4 4
Item Description Part No.
1 Capacitor-Start 72-88UF/330V 059757
2 Capacitor-Start 161-193UF/25 031790
3 Relay-Start-Compressor 047067
4 Screw-10x3/8 Slotted Hex 015582
5 Bushing-Snap 11/16 ID x 7/8OD 010548
Item Description Part No.
6 Strap-Capacitor 7-11/32 037890
7 Capacitor-Run 30UF/370V 038487
8 Strap-Capacitor 5-5/8 IN. 030258
9 Capacitor-Run 10UF/370V 059998
* Harness-Wire-Cap/Relay 063975-27

Taylor C152 Specifications

General

Brand	Taylor
Model	C152
Category	Freezer
Language	English
