Taylor C152 Service Manual

4-18
PARTS
Model C152 & C161
Parts
4
X69423 Control A.-Channel (Model C161)
Figure 4-12
1e
1b
1a
2
4
3
1g
5
1c
1f
1d
1b
6
Item Description Part No.
1 Switch A.-Draw 
(Includes Items 1a-1g)
X85566
1a Bearing-Switch 029244
1b Nut-Push On-1/2DIA. Shaft 039735
1c Screw-4-40x5/8 Sltd 027219
1d Switch-Lever-Spdt 027214
1e Insulator-Switch 1/64 029099
Item Description Part No.
1f Screw-6-32x3/8 Sltd 002201
1g Bracket-Switch 085567
2 Spring-Comp.720x.063x2.00 023664
3 Actuator-Switch-Plastic 035609
4 E-ring-1/4 in-ZD 034962
5 Arm A.-Switch X30736
6 Bushing-Snap 15/16 ID x 1-3/32 023396
