Section 11 Parts List

Model C712

Parts List

100901

DESCRIPTION PART

NUMBER

QTY. WARR.

CLASS

COMMENTS

ACTUATOR A.-DRAW SWITCH X62401 1 103

ARM-SWITCH-DRAW-L 038649 1 103

ARM-SWITCH-DRAW-R 038650 1 103

BRACKET A.-SPRING RETURN X38257 1 103

E-RING 1/4 032190 4 000

PIN-PIVOT-DRAW SWITCH 038484 1 103

ROD-SPRING RETAINER 038254 1 103

SPRING-EXTENSION.375X.045X1.00 038922 2 103

SPRING-RETURN-LEFT-TWIN TWIST 038923 1 103

SPRING-RETURN-RIGHT-TWIN TWIST 038924 1 103

BEARING-REAR SHELL-NICKEL 031324 2 000

+NUT-BRASS BEARING 028991 2 000

+GUIDE-DRIP SEAL 028992 2 000

+WASHER-BEARING L OCK 012864 2 000

BEATER A.-3.4QT-1 PIN-SUPPORT X46231 2 103

+BLADE-SCRAPER-PLASTIC 8-1/8L 046235 4 000

+CLIP-SCRAPER BLADE 7.00 INCH 046236 4 103

BELT-AX32 032769 4 000

BELT-AX33 024396 4 000 220-240V 50HZ 1PH

BLOWER A. X53725-27 1 103

CAPACITOR-RUN 7.5UF/370V 034749 1 103

CLIP-SCREEN-BLOWER 053730 4 103

MOTOR-FAN 208-230V 50/60 HZ 053481-27 4 103

SCREEN-BLOWER 053729 1 103

WHEEL-BLOWER 053726 1 103

BOOT-VALVE-EXPANSION 050900 2 000

BRUSH-DBL END-PUMP & FEED TUBE 013072 1 000

BRUSH-DRAW VALVE 1"OD X 2"X17" 013073 1 000

BRUSH-END-DOOR-SPOUT-SS-HT 039719 1 000

BRUSH-MIX PUMP BODY-3" X 7 " WH 023316 1 000

BRUSH-PUMP SPOUT *MC13* 054068 1 000
