1-6
INTRODUCTION
Models C712/C713
Introduction
1
Model C713 Specifications
Freezing Cylinder
Two, 3.4 qt. (3.2 L)
Mix Hopper
Two, 20 qt. (18.9 L)
Beater Motor
Two, 1.5 hp
Refrigeration Machine
Two, approximately 9,500 BTU/hr compressors
Refrigerant R404A.
Electrical
Table 1-2
This machine may be manufactured in other electrical
characteristics. Refer to the local Taylor distributor for
availability. (For exact electrical information, always see
the data label of the machine.)
Air-Cooled
Clearance: A minimum of 3 in. (76 mm) is required
around all sides. Install the deflector provided to prevent
recirculation of warm air.
Water-Cooled
Water inlet and drain connections under the side of the
base, 1/2 in. FPT.
Dimensions
Width: 25-7/16 in. (646 mm)
Height: 60 in. (1524 mm)
Depth: 36-3/16 in. (919 mm)
Floor Clearance*: 4-3/4 in. (121 mm)
*Mounted on standard casters
Approximate Weights
Net: 733 lbs. (333 kgs)
Crated: 810 lbs. (367 kgs)
Volume: 67.5 cu. ft. (1.91 cu m)
Electrical
Maximum
Fuse Size
Minimum
Circuit
Ampacity
Left Right Left Right
208-230/60/1 Air 35 35 25 23
208-230/60/1 Air, Syrup 35 35 26 23
208-230/60/1 Water 35 35 25 23
208-230/60/3 Air 25 25 19 17
208-230/60/3 Water 20 20 17 15
220-240/50/1 Water 25 25 21 19
380-415/50/3N~Air 12 10 9 8
