5-14
PARTS LIST
Models C712/C713
Parts List
+ Available Separately
5
Valve-EXP-Auto-1/4S X1/4 FPT 046365 2 2 103
+Boot-Valve-Expansion 050900 2 2 000
Valve-Solenoid 7/64ORF X 1/4S 043449-27 2 2 103
Water Cooled
Accumulator-Copper 2"DIA 10" 047062 2 2 103
Blower-100 CFM 012796-27 1 1 103
+Guard-Blower 022505 1 1 103
Condenser-WC-Coax 047540 2 2 103
Hose-Rubber 1/2 ID X 7/8 OD R50200 15 15' 000
+Clamp-Hose 3/4 ID CONST TENSN 067113 8 8 000
Outlet A.-TEE X25900 1 1 103
Panel-Side-L. W/C *C712/C717 062160 1 1 103
Panel-Side-R. W/C *C712/C717 062161 1 1 103
Plate-Condenser W/C 062043-SP 1 1 103
Pipe TEE 3/8-Water Valve-Blk 032953 1 1 103
Switch-Pressure 350 PSI-SOLD 048231 2 2 103
Valve-Water 3/8 Reg/Head Press 046686 2 2 103
50HZ/60HZ w/High V - 50HZ
C71235F000 & C71335F000 - 220-240V 50HZ 3PH, C71337R974 - 200V 50HZ 3PH, C71239FW00 & C71339R000 - 200V 50/60HZ 3PH,
C71240FW00 & C71340FW00 - 220-240V 50HZ 1PH, C71258FW00 & C71358FW00 - 380-415V 50HZ 3N~ (4WIRE),
C71260FW00 & C71360F000 - 220-380V 60HZ 3PH-4 WIRE
Belt-AX33 024396 4 000 220-240V 50HZ 3PH/C712 220-240V 50HZ
1PH/380-415V 50HZ 3N~(4WIRE)
Belt-AX32 032769 4 4 000 200V 50HZ 3PH/200V 50/60HZ 3PH / 220-380V 60HZ
3PH-4 WIRE
Belt-AX31 041575 4 000 C713 220-240 50HZ 1PH/C713 380-415V 50HZ
3N~(4WIRE)
Description
Part
Number
C712
Qty.
C713
Qty.
Warr. Class Remarks
To Next Page
