Taylor C712 Service Manual

5-2 PARTS LIST
Models C712/C713
Parts List
+ Available Separately
5
C71227F000 & C71327F000
Description
Part
Number
C712
Qty.
C713
Qty.
Warr. Class Remarks
Actuator A.-Draw Switch *C71X* X69835 1 1 103 M0114575 and up
Arm-Draw Switch-Left 069166 1 1 103
Arm-Draw Switch-Right 069167 1 1 103
Bracket A.-Spring-Return X69481 1 1 103
E-Ring 1/4 Black PHOS 032190 3 3 000
Pin-Pivot-Draw Switch 038484 1 1 103
Rod-Spring Retainer 038254-SP 1 1 103
Screw-Adjustment-Draw Paddle 069374 2 2 000
Spring-Extension.467x.062x1. 069392 2 2 103
Spring-Return-Left-Twin TWIS 038923 1 1 103
Spring-Return-Right-Twin TWI 038924 1 1 103
Actuator A.-Draw Switch X62401 1 1 103
Arm-Switch-Draw-l 038649 1 1 103
Arm-Switch-Draw-r 038650 1 1 103
Bracket A.-Spring Return X38257 1 1 103
E-ring 1/4 032190 4 4 000
Pin-Pivot-Draw Switch 038484 1 1 103
Rod-Spring Retainer 038254 1 1 103
Spring-Extension.500X.054X1. 067352 2 2 103
Spring-Return-Left-Twin Twist 038923 1 1 103
Spring-Return-Right-Twin Twist 038924 1 1 103
Bearing-Rear Shell-Nickel 031324 2 2 000
+Nut-Brass Bearing 028991 2 2 000
+Guide-Drip Seal 028992 2 2 000
