Introduction
VoiceLive 3 – Reference manual (2014-03-29) 19
Back panel inputs and outputs
VoiceLive 3 offers extremely robust input and
output routing. Using the Monitor IN/THRU and
dedicated Guitar outputs effectively, you can
greatly reduce the amount of gear you need to
take to a performance.
Inputs
SWITCH-3
4
2 3 6 57 1
VoiceLive 3 inputs overview
1. DC Power connector
2. XLR & ¼” Combo jack
3. ¼” Guitar input
4. 1/8” Stereo Aux input jack.
Please note that Aux input and Monitor input
are mutually exclusive. Only one may be used
at a time.
5. MIDI In
6. Footswitch (for Switch-3) In.
You can also connect a second expression
pedal here – see “Working with a second ex-
pression pedal”.
7. Expression (pedal) In
