TC-Helicon VoiceLive User Manual

21
PRESET EDIT SCREENS
Pressing the EDIT key while in Preset Mode gives access to the edit parameters. Turning the data
wheel scrolls through the edit screens. Each edit screen has up to four parameters that may be
adjusted with the EDIT knobs. This section of the manual goes screen by screen to describe the
parameters in VoiceLive. To leave the edit screens press the EDIT key.
Configuration Screens
The parameters in this section are used to enable/disable the harmony and effect components of a
preset.
These parameters allow enabling/disabling of Harmony, Thickening, Effects and Pitch correction
audio components. The Voices and Effects LEDs will reflect the settings of this page.
EDIT 1 knob: E
NABLE/DISABLE
HARMONY V
OICES
EDIT 2 knob: ENABLE/
DISABLE LEAD VOICE THICKENING
EDIT 3 knob: ENABLE/DISABLE EFFECTS (Reverb and Delay)
EDIT 4 knob: ENABLE/DISABLE PITCH CORRECTION
These parameters allow enabling/disabling of individual harmony voices. Voices and Effects LEDs
will reflect the settings of this page.
EDIT 1 knob: ENABLE/DISABLE
VOICE 1
EDIT 2 knob: E
NABLE/DISABLE VOICE 2
EDIT 3 knob: ENABLE/DISABLE
VOICE 3
EDIT 4 knob: E
NABLE/DISABLE VOICE 4
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Voice Enable
Cfg2
On On Off Off
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Harm Thk FX Cor
Cfg1
On Off On On

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
