FOOTSWITCH FUNCTION TABLES
Song Mode Footswitch Functions: Buttons 1-4
Submode Action Button 1 Button 2 Button 3 Button 4
Press
Song Select Song Step Select Rewind to Step 1 N/A
Normal
Hold
Enter Preset Mode N/A Enter Direct Mode Enter Voice Mode
Press
Goto Direct A Step Goto Direct B Step Goto Direct C Step Goto Direct D Step
Direct
Hold
Program Direct A* Step OR Enter Preset Mode
Program Direct B* Step OR Enter Song Mode
Program Direct C* Step Program Direct D* Step OR
Enter Voice Mode
Press
Enable/Disable Voice 1
Enable/Disable Voice 2 Enable/Disable Voice 3 Enable/Disable Voice 4
Voice
Hold
Enter Preset Mode Enter Song Mode Enter Direct Mode Enter Voice Mode
Song Mode Footswitch Functions: Buttons 5-8
Submode Action Button 5 Button 6 Button 7 Button 8
Press
Decrement Song# or Song Step#
Increment Song# or Step# User defined function Mute/ Unmute Harmony
Voices
Normal
Hold
Repeat Decrement Song# or Step#
Repeat Increment Song# or Step#
User defined function Bypass/ Unbypass
Press
Decrement Song Step# Increment Song Step# User defined function Mute/ Unmute Harmony
Voices
Direct
Hold
Repeat Decrement Song Step#
Repeat Increment Step# User defined function Bypass/ Unbypass
Press
Decrement Song Step Number
Increment Song Step# User defined function Mute/ Unmute Harmony
Voices
Voice
Hold
Repeat Decrement Step # Repeat Increment Step# User defined function Bypass/ Unbypass
* Direct buttons are programmed when the second character of the LED display is a *, otherwise the mode is changed.

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
