PRESET EDIT SCREENS
Voice Edit Screens
VoiceLive can create up to 4 harmony voices. The parameters in this section allow adjustment of
the individual voices.
This screen is used to set the output level of the individual harmony voices. Please note that there
is also a master harmony voice level found on edit screen HA 1.
EDIT 1 knob: V
OICE 1 LEVEL
EDIT 2 knob: VOICE 2 LEVEL
EDIT 3 knob: VOICE 3 L
EVEL
EDIT 4 knob: VOICE 4 LEVEL
This screen is used to set the pan position of the individual harmony voices.
EDIT 1 knob: V
OICE 1 PANNING
EDIT 2 knob: VOICE 2 PANNING
EDIT 3 knob: V
OICE 3 PANNING
EDIT 4 knob: VOICE 4 PANNING
This screen is used to set the voicing of the four harmony voices. Voicing means setting the harmo-
ny voice note/pitch with respect to the lead note/pitch. This parameter means different things for dif-
ferent harmony modes. The harmony mode of the preset is shown on the LCD display.
EDIT 1 knob: V
OICE 1 VOICING
EDIT 2 knob: VOICE 2 VOICING
EDIT 3 knob: VOICE 3 VOICING
EDIT 4 knob: VOICE 4 VOICING
Note: the EDIT knobs will have no effect with Notes mode presets.
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Voicing Scale
Vo 3
--4 -8 +3 +5
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Voice Pan
Vo 2
L99 R99 L45 R34
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
Voice Level (dB)
Vo 1
-3 -8 0 -2

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
