Panel Memory Output
These are settings affect the transmission data when the PANEL MEMORY buttons are operated.
1. On the MIDI MENU display, select PANEL
MEMORY OUTPUT.
• The display looks similar to the following.
2. Use the P.MEM ∧ and ∨ buttons to select a
PANEL MEMORY number.
3. Use the OFF/ON ∧ and ∨ buttons to specify
whether the data in the selected PANEL
MEMORY number is transmitted or not.
4. Use the PART ∧ and ∨ buttons to select a
part (RIGHT 1, RIGHT 2 or LEFT).
5. Use the PRGRAM CHANGE ∧ and ∨ buttons
to specify a program change number (0 to 127,
or OFF).
6. Use the BANK LSB ∧ and ∨ buttons to specify
a BANK LSB (0 to 127).
7. Use the BANK MSB ∧ and ∨ buttons to specify
a BANK MSB (0 to 127).
8. Use the VOLUME ∧ and ∨ buttons to specify
the volume (0 to 127, or OFF).
9. Repeat steps 4 to 7 for each part, as neces-
sary.
10.Repeat steps 3 to 9 for each PANEL MEMORY
number, as necessary.
Computer Connection
These settings are used to select the mode related to MIDI signal flow when a personal computer is
connected to the USB terminal of this instrument.
• When connecting to a personal computer, install the USB driver on the included CD-ROM to the
computer first. (Refer to the separate manual for more information.)
1. Turn off the power to this instrument.
2. Connect a personal computer to the USB ter-
minal on the rear of this instrument.
3. Turn on the power to this instrument.
4. On the MIDI MENU display, select COM-
PUTER CONNECTION.
• The display looks similar to the following.
5. Use the ∧ and ∨ buttons to select a mode.
NORMAL:
Ordinary mode
PC as master:
The mode which is appropriate for data trans-
mission
KN as master:
The mode when this instrument is used as the
master keyboard.
KN as slave:
The mode when this instrument is used as a
slave instrument.
INTERFACE:
The mode when this instrument is used as a
connecting device between a PC with only
USB terminals and an instrument with only
MIDI terminals.
MIDI
Part XIII MIDI
196
QQTG0671
