Tektronix AWG7000B Series User Manual

Replaceable Parts
Table 5-13: Rep
laceable parts list – AWG7000C Series PCI/power interface module
Fig. & index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont’d Qty Name & descrip
tion
5-13-
PCI/POWER INTERFACE MODULE
-1 174-5246-00 1
CABLE ASSY ELEC: 2 X 12P,31IN L,AWG16 X 24,39-01-2245,
39-01-2245,MOLEX
-2 174-4798-00 1
CABLE ASSEMBLY; 4 PIN P4 POWER,SAFETY CONTROLLED
-3 174-4797-00 1
CABLE ASSEMB
LY; 20 PIN ATX POWER,SAFETY CONTROLLED
-4 346-0128-00 2
STRAP,TIEDOWN;8.0 L X 0.1 W,NYLON
-5
211-1050-0
0
10
SCREW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-6 679-6064-03 1
CIRCUIT BOA
RD ASSY; POWER DC-DC, 389-3775-00
(INCLUDES 4)
-7
343-1701-00 1
CLAMP,CAB
LE; WITH ADHESIVE BACK
-8 348-1952-00 1
GROMMET, PLASTIC; U SHAPE, 2.210 L, NATURAL,
RICHCO#M
SG-1-01
-9 174-5245-00 1
CABLE ASSY ELEC: FLAT CABLE,TWISTED PAIR,68P,0.05 PITCH,
20IN L,SD
A-71660-3568,MOLEX
-10 335-0347-00
MARKER,IDENT; REAR PANEL,BLANK,2.100 X 2.700,SAFETY
CONTROL
LED
-11 335-1663-00 1
MARKER,IDENT; LABEL,COSMETIC,REAR,LEXAN, SAFETY
CONTRO
LLED
-12 174-5307-00 1
CABLE ASSY ELEC: GPIB,5INL,BOARD TO REAR PANEL,24P
GPIB CO
NN TO 24P HEADER CONN,W/O JACK SCREW, SAFETY
CONTROLLED
-13 335-1668-00 1
MARKE
R,IDENT; LABEL, I/O FOR PCI PCB (ATTACHES TO PCI PCB
BRACKET), SAFETY CONTROLLED
-14 211-1050-00 6
SCREW
,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-15 213-1061-00 2
JACKSCREW; 6-32 X 0.320 EXT THD,M3.5 X 0.6-6 INT THD X 0.215L,
GPIB
, BLACK OXIDE, BULK PACK
-16 211-1206-01 2
SCREW,JACK; 2-56 ID X 4-40 OD,0.188 HEX,SS
-17 386
-7462-01
1
BRACKET, REAR: MIO
-18 211-1050-00 1
SCR
EW,MACHINE; 6-32 X 0.312 L,PNH,STL CAD PLT,T15
-19 870-0474-00 1
CIRCUIT BOARD ASSEMBLY; MIO WITH PCIE, MULTI
-I/
O,FUNCTIONAL BOARD TESTED
INCLUDES 20 AND 21
-20 343-1627-00 1
CA
BLE,CLAMP; 0.5H X 2.98L,0.625 W,NYLON 6-6, ADHESIVE,COVER
343-1636-00
-21 343-1636-00 1
CL
AMP, COVER; FLT CABLE ROUTING CLAMP, 343-1627-00 BASE
-22 174-5629-00 1
CABLE, LVDS VIDEO WITH 2X20 HIROSE CONNECTORS
-
23
3
35-2289-00
1
MARKER,IDENT; LABEL,COSMETIC,REAR,AWG,LEXAN, SAFETY
CONTROLLED
-24 335-2290-00 1
MARKER,IDENT; LABEL,REAR I/O,MAIN,LEXAN, SAFETY
CONTROLLED
5–24 AWG7000B and AWG7000C Series Service Manual
