Tektronix DPO5204 User Manual

Acquisition
Quick Tips
Digital channels and buses are not available in FastAcq mode.
To optimize for capturing details or rare events, select Horiz/Acq > Horizontal/Acquisition Setup > A cquisition> Fast
Acq, and then select Optimize For Capturing Details or Capturing rare events.
On MSO5000 and DPO5000 Series instruments, Fast Ac q m ode is not available in XY or XYZ Display modes.
44 MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual

Tektronix DPO5204 Specifications

General

Bandwidth	2 GHz
Channels	4
Input Voltage Range/Maximum Input Voltage	±40 V
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Interface	USB, LAN, GPIB
Operating Temperature	0 °C to +50 °C
Trigger Modes	Edge, Sequence, Pulse Width, Timeout, Runt, Logic, Video
Sample Rate	10 GS/s (All Channels)
Display	12.1 in. (307 mm) LCD
Input Impedance	1 MΩ ± 2% // 15 pF
