Display
a
Wavef
o
rm
Selecting
the
W
aveform
Interpolation
Select
Displa
y
>
Waveform
Interpolation
,
and
then
select
one
of
the
following:
Sin(X)/X
interpolation
computes
record
points
using
a
curve
fi
t
between
the
actual
sampl
es
acquired.
Linear
inter
polation
computes
record
points
between
actual
acquired
samples
by
using
a
straight
line
fi
t.
