Acquisition
Setting
Up
a
B
us
Y
ou
can
set
up
serial
and
parallel
buses
on
MSO70000/C,
MSO5000,
and
DPO5000
Series
instruments.
1.
Select
V
ertical
>
Bus
Setup
or,
on
some
instruments,
Digital
>
Bus
Setup
.
2.
Select
the
Con
fi
g
tab.
50
MSO70000/C,
DPO/DSA70000B/C,
DPO7000,
and
MSO/DP
O5000
Series
U
ser
M
anual
70
72
