Display a Wavefo
rm
6. To adjust the zo
omed area vertically,
select Vertical > Zoom Setup...,
click a vertical field, and then use the
multipurpose
knobs to adjust the Vertical
Position and Factor.
Quick Tips
To clear th
e zoom area, click Position Factor Reset from the Z oom Setup control window.
Turn each
zoom display on and off from the Zoom Setup control window.
Push the M
ultiView Zoom button to toggle all zoom displays on and off.
To reposi
tion the zoomed area horizontally, click and drag the horizontal marker at the bottom of the zoom box.
Use Wave
Inspector to manage long record length waveforms. (See page 103, Using Wave Inspector to Manage
Long Record Length Waveforms.)
100 MSO70000/C, DPO/DSA70000B/C, DPO7000, and MSO/DP O5000 Series U ser M anual
