Tektronix KEITHLEY 2200 Series User Manual

Command Groups
Table 2 -12: Source commands (cont.)
Command Description
[SOURce:]OUTPut:ENABle Set or query the current channel as enabled or disabled.
[SOURce]:CHAN nel:OUTPut:[STATe] Set or query the output status of the current channel.
[SOURce:]APPly S ets voltage and current level and switch channels at the same
time.
[SOURce:]OUTPut:PARallel[:STATe] Sets the parallel state of CH1 and CH2.
[SOURce:]OUTPut:SE Ries Sets the serial state of CH1 and CH2.
[SOURce:]OUTPut:PO N[:STATe] Sets the power supply to power up with its output turned off, or to
return the output to the s tate it was in when it powered down.
Channel C om bination Commands
These commands allow you to set various channel combinations. The commands
you ca
n use depends on the number of channels your instrument has.
Table 2-13: Channel combination commands
Command Description
INSTrument:SELect Switch or query the current channel.
INSTrument:COMbine:SERies Set CH1 and CH2 i n series.
INSTrument:COMbine:PARAllel Set CH1 and CH2 in parallel.
INSTrument:COMbine:TRACk Set CH1 and CH2 to track.
INSTrument:COMbine:OFF Remove the combination of channels.
INSTrument:COMbine? Query which channels are combined.
Display Commands
Display commands are used to clear of show particular strings on the instrument
display.
Table 2-14: Display commands
Header Description
DISPlay[:WINDow][:STATe] Set or query the display state.
DISPlay[:WINDow]:TEXT[:D ATA] Set or query the display to show a particular string.
DISPlay[:WINDow]:TEXT:CLEar Set to clear the characters on the display and returns the display
to normal mode.
2-12 Series 2200 Programmable Multichannel DC Power Supplies Programmer Manual
