Save and Recall I
nformation
Save
Setup
To File
Edit Labels
3. From the resul
ting side menu, select the
location to save the setup to or to recall it
from.
To save setup i
nformation to one of the ten
internal setup memories in the oscilloscope,
push the appropriate side menu button.
To save setup
information to a USB or
network drive, push the To File button.
To Setup 1
To Setup 2
–more–
4. IfyouaresavinginformationtoaUSBor
network dr
ive, turn Multipurpo se a to sc roll
through the file structure. (See page 162,
External file structure.)
Push S elect to open or close file folders.
Push the Menu Off button to cancel the save
operation, or push Save to Selected File on
the side m enu to complete the operation.
MDO3000 Series Oscilloscopes User Manual 169
