Tektronix RSA306B Technical Reference

Specifications
Specification
s
All specifications are guaranteed unless labeled Typical. Typical specifications are provided for your convenience.
NOTE. Warranted characteristics that are checked in the Performance Verifi cation are marked with a
 symbol.
The performance limits in this specification are valid within the following conditions:
The S ignalVu-PC software version is 3.7.0114 or greater.
Operate the instrument in an environment that meets the temperature, altitude, and humidity characteristics listed in
these specifications.
The instrument must have been operating for a warm-up period of at least for 30 minutes (after being connected to the
PC, starting the SignalVu-PC application, and SignalVu-PC is connected to the RSA306B instrument and continuously
acquiring data).
NOTE. The RSA306B does not fully power on until SignalVu-PC has established communication with the R SA306B
and is acquiring data.
The instrument must have had its signal–path–compensation routine last executed after at least a 30 minute warm–up
period at an ambient temperature within ± 2 °C of the current ambient temperature.
RSA306B Specifications and Performance Verification 1
