Tektronix TDS 520D Technical Reference

Performance Tests
1–98
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Table 1–9: Option 3C and 4C specifications
Name Description
Calibration Range, Reference Receiver 10 mW per division
20 mW per division
50 mW per division
Temperature Range, Warranted Filter 23_ C, "5_ C
Calibration Range, Controlled Up to 2X the data rate for all filters except
FC1063 filter
Up to 1.5X the data rate for FC1063 filter
Table 1–10: Available receivers
Option 4C
1
Option 3C
2
OC1
4
OC3 OC12 FC1063
3
FC133 FC266 FC531 FC1063
3
OC3 OC12
TDS 520D n n n n
TDS 540D n n n n n n n n
TDS 580D n n n n n n n n n n
TDS 724D n n n n
TDS 754D n n n n n n n n
TDS 784D n n n n n n n n n n
1
Requires Tektronix P6703B, 1300 nm Optical to Electrical Converter.
2
Requires Tektronix P6701B, 850 nm Optical to Electrical Converter.
3
Reference receivers are warranted to 2.0 times the bit rate except for FC1063 which is warranted to 1.5 times the bit rate.
4
OC1 is type tested
