Tektronix TDS 520D Technical Reference

Typical Characteristics
2–30
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Table 2–16: Typical characteristics — Signal acquisition system (cont.)
Name Description
Analog Bandwidth, DC-50 W Coupled
with P6139A Probe (TDS 654C) or P6245
Volts/Div as read out on screen
TDS 654C
Bandwidth
1
TDS 680C & 684C
Bandwidth
1
Probe (TDS 680C & 684C) and Bandwidth
10 V/div – 100 V/div
(Not Applicable) (Not Applicable)
selection is FULL
TDS 600C
100 mV/div – 10 V/div
DC – 500 MHz DC – 1 GHz
50 mV/div – 99.5 mV/div DC – 450 MHz DC – 750 MHz
20 mV/div – 49.8 mV/div DC – 300 MHz DC – 600 MHz
10 mV/div – 19.9 mV/div DC – 250 MHz DC – 500 MHz
Accuracy, Delta Time Measurement The limits are given in the following table for signals having amplitude greater than
5 divisions, reference level = 50%, filter set to (sinX/X), acquired at 5 mV/div or greater.
For the TDS 700D/714L, pulse duration < 10 division. Channel skew not included.
TDS 600C: For the averaged condition, 1.4 ≤ T
r
/W
i
≤ 40, where W
i
is the Waveform
Interval, as described elsewhere in these specifications.
Extra error in the measurement will occur for two-channel measurements due to
channel-to-channel skew. This is described elsewhere in these specifications.
Time measurement accuracy
Conditions for accuracy listed at right
are: ≥ 100 Averages, with Full Band-
width selected, and for
TDS 500D/700D/714L, repetitive
mode.
TDS 600C: ±(10 ps + (100 ppm × | Reading |) + (0.2 × W
i
) )
TDS 500D/700D/714L: ±(20 ps + (25 ppm × | Reading |) + (0.15 × W
i
) )
TDS 694C: ±(5 ps + (10 ppm × | Reading |)
Calculated Rise Time, TDS 600C
2
(except TDS 694C) Volts/Div setting
TDS 654C
Rise time
TDS 680C & 684C
Rise time
10 mV/div – 1 V/div 900 ps 450 ps
5 mV/div – 9.95 mV/div 1 ns 600 ps
2 mV/div – 4.98 mV/div 1.5 ns 750 ps
1 mV/div – 1.99 mV/div 1.8 ns 900 ps
Calculated Rise Time,
TDS 500D/700D/714L
2
Volts/Div setting
520D, 540D, 714L,
724D, & 754D Rise
time
580D & 784D
Rise time
10 mV/div – 1 V/div 800 ps 400 ps
5 mV/div – 9.95 mV/div 800 ps 530 ps
2 mV/div – 4.98 mV/div 800 ps 600 ps
1 mV/div – 1.99 mV/div 890 ps 800 ps
Calculated Rise Time, Volts/Div setting 694C Rise time
TDS 694C
2
10 mV/div – 1 V/div 133 ps
Calculated Rise Time, Volts/Div setting 794D Rise time
TDS 794D
2
10 mV/div – 1 V/div 200 ps
