Performance Verification
4-14
TDS1000B and TDS2000B Series Oscilloscope Service Manual
Measured Position
Error
Lower limit
Upper limit
Measured
Error
Figure 4- 1: Example of a line graph for the Vertical Position Accuracy test

Tektronix TDS2014B Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GS/s
Display Type	LCD
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Display Size	5.7 inches
Vertical Sensitivity	2 mV to 5 V/div
Trigger Modes	Edge, Pulse, Video
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 50/60 Hz
Interfaces	USB
