Maintenance
TDS1000B and TDS2000B Series Oscilloscope Service Manual
6-- 13
5. Remove the display.
6. Disconnect the display cable on the display module.
7. Thread the cable out of the chassis.
Installation. To install the display cable, refer to Figure 8--3 and follow these
steps:
1. Remove the display module using the procedure on page 6--16.
2. Attach the display cable to the appropriate connector on the display module
at the location shown in Figure 8--3: 12-pin for the monochrome display, and
15-pin for the color display.
3. With the display module in place but not connected, thread the display cable
through the appropriate slot on the chassis.
4. Twist the cable to keep it from contact with the boards and chassis.
NOTE. Wind up the display cable until it is tight; loops are okay. This keeps the
cable bundle together.
5. Connect the display cable at J201 on the main board by pushing the cable
straight down into the connector.
6. Secure the display cable to the chassis with the cable tie.
7. Apply 3 strips of 3M Electrical Tape 92 to secure the cable to the chassis.
Figure 6--3 shows where to apply the tape for good results.
