82
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
7 MAINTENANCE
7.24 Planetary Oil Change (see section 7.3)
1. Place the machine on mechanical supports
as described in section 7.23, then orient
the perimeter drain plug at the very
bottom of the drive motor and turn the
engine off. Remove the key to avoid
accidental start.
2. Remove the plug and drain the oil into a
suitable catch container. Dispose
according to mandates (fig 7.24-1).
3. Start the machine (make sure all personnel
are clear of the machine), then roll the
drive motor over so that the drain/fill hole
is on the very top of the drive motor. Stop
the engine and remove the key to avoid
accidental start.
4. Fill the planetary with .95qt (.9l) of 75-140
synthetic gear oil, reinstall plug.
5. Repeat the procedure on the opposite
drive motor.
7.24-1
drain
plug
Drain
Fill
