Circuit Module Physical Layout, Bill of Materials and Schematic
www.ti.com
18
SLUUBI1A–October 2016–Revised July 2018
Submit Documentation Feedback
Copyright © 2016–2018, Texas Instruments Incorporated
bq34110EVM-796 Evaluation Module
4.2 Bill of Materials
Table 6 lists the BOM for this EVM.
Table 6. Bill of Materials
Qty Reference
Designator
Value Description Size Part Number Manufacturer
1 C1 3300pF CAP, CERM, 3300 pF, 50 V, +/- 10%, X7R, 0603 0603 GRM188R71H332KA01D Murata
4 C2, C3, C4, C5 0.1uF CAP, CERM, 0.1 µF, 50 V, +/- 10%, X7R, 0603 0603 GRM188R71H104KA93D Murata
1 C6 1uF CAP, CERM, 1 µF, 50 V, +/- 10%, X7R, 0805 0805 GRM21BR71H105KA12L Murata
1 D1 5.6V Diode, Zener, 5.6 V, 300 mW, SOD-523 SOD-523 BZT52C5V6T-7 Diodes Inc.
1 H1 Cable Used in PnP output CBL002 Any
1 J1 Header (friction lock), 100mil, 4x1, R/A, TH 4x1 R/A Header 22-05-3041 Molex
1 J2 Header, 100mil, 8x1, Tin, TH Header, 8x1, 100mil, TH PEC08SAAN Sullins Connector Solutions
3 J3, J8, J10 Header, 100mil, 2x1, Tin, TH Header, 2 PIN, 100mil, Tin PEC02SAAN Sullins Connector Solutions
2 J4, J5 Header, 100mil, 3x2, Tin, TH 3x2 Header PEC03DAAN Sullins Connector Solutions
1 J6 Terminal Block, 3.5mm Pitch, 5x1, TH 17.5x8.2x6.5mm ED555/5DS On-Shore Technology
1 J7 Terminal Block, 3.5 mm, 3x1, Tin, TH Terminal Block, 3.5 mm,
3x1, TH
39357-0003 Molex
1 J9 Terminal Block, 3.5 mm, 2x1, Tin, TH Terminal Block, 3.5 mm,
2x1, TH
39357-0002 Molex
1 Q1 60V MOSFET, N-CH, 60 V, 0.17 A, SOT-23 SOT-23 2N7002-7-F Diodes Inc.
1 Q2 -50V MOSFET, P-CH, -50 V, -0.13 A, SOT-323 SOT-323 BSS84W-7-F Diodes Inc.
1 Q3 50V MOSFET, N-CH, 50 V, 0.2 A, SOT-323 SOT-323 BSS138W-7-F Diodes Inc.
1 Q4 30V MOSFET, N-CH, 30 V, 5 A, SON 2x2mm SON 2x2mm CSD17313Q2 Texas Instruments
1 R1 10k RES, 10k ohm, 5%, 0.1W, 0603 0603 CRCW060310K0JNEA Vishay-Dale
3 R2, R10, R11 100k RES, 100 k, 1%, 0.1 W, 0603 0603 CRCW0603100KFKEA Vishay-Dale
2 R3, R4 10.0k RES, 10.0 k, 1%, 0.1 W, 0603 0603 CRCW060310K0FKEA Vishay-Dale
1 R5 165k RES, 165 k, 1%, 0.1 W, 0603 0603 CRCW0603165KFKEA Vishay-Dale
4 R6, R7, R16, R20 100 RES, 100, 1%, 0.1 W, 0603 0603 CRCW0603100RFKEA Vishay-Dale
1 R8 16.5k RES, 16.5 k, 0.1%, 0.1 W, 0603 0603 RG1608P-1652-B-T5 Susumu Co Ltd
3 R9, R12, R13 300k RES, 300 k, 0.1%, 0.1 W, 0603 0603 RG1608P-304-B-T5 Susumu Co Ltd
4 R14, R15, R17, R19 1.0k RES, 1.0k ohm, 5%, 0.1W, 0603 0603 CRCW06031K00JNEA Vishay-Dale
1 R18 0.01 RES, 0.01, 1%, 1 W, 2010 2010 WSL2010R0100FEA18 Vishay-Dale
1 R21 20 RES, 20, 5%, 1 W, AEC-Q200 Grade 0, 2512 2512 CRCW251220R0JNEG Vishay-Dale
1 R22 1.0Meg RES, 1.0 M, 5%, 0.1 W, 0603 0603 CRCW06031M00JNEA Vishay-Dale
1 RT1 10.0k ohm Thermistor NTC, 10.0k ohm, 1%, Disc, 5x8.4 mm Disc, 5x8.4 mm 103AT-2 SEMITEC Corporation
3 TP1, TP2, TP3 White Test Point, Miniature, White, TH White Miniature Testpoint 5002 Keystone
1 U1 Multi-Chemistry CEDV Gas Gauge for Rarely Discharged
Applications, PW0014A
PW0014A BQ34110PWR Texas Instruments
