Chapter 3
DLPU030B–June 2015–Revised July 2015
Operating the DLP NIRscan Nano EVM
3.1 NIRscan Nano GUI
Upon execution of the NIRscanNanoGUI.exe, the software checks for the DLP NIRscan Nano EVM
enumerating through USB and displays the information screen shown in Figure 3-1. The GUI is divided
into two sections:
• The top section displays the connected state of the DLP NIRscan Nano EVM on the top-right side. It
also has four buttons:
– Information: Changes the bottom portion of the GUI to display version information, and links to
online resources.
– Scan: Changes the bottom portion of the GUI to display spectrum plots and controls for scan
configurations and parameters.
– Utilities: Changes the bottom portion of the GUI to display sensor information and to synchronize
data and time with PC, ADC PGA settings, and firmware upgrades.
– Connected Status Button: Once a DLP NIRscan Nano enumerates, the icon in the connected status
button will change from a gray indicator light with a "Not Connected" message to a green indicator
light with a "Connected" message. Pressing this button has no effect. Disconnecting the DLP
NIRscan Nano, powering down the device, or resetting the DLP NIRscan Nano will toggle the state
of this button.
• The lower section displays information related to the three main operational modes: information, scan,
and utilities.
