Fax/Data Panel Operation
The cabin fax/data panels are used for either fax or data transmission. The
panels utilize RJ-11 jacks for fax or a computer can be plugged into the 9-pin
serial jacks. For detailed operation instructions, see the user manual of the type
of equipment connected to the fax/data panel.
Note: Each fax/data panel is configured by the telephone in closest proximity to
that switch panel.
RJ-11 Jack
9-Pin Serial Jack
On Left-Hand Chart Case
In Left-Hand Sidewall Storage
Compartment
