User’s manual User’s manual
GB
 49
(Type R4GBD2-Mk22)
9 - Installation ............................................................................. 73
9.1 - Radiator composition ................................................ 73
9.2 - Installing your radiator .............................................. 73
9.3 - Fix the wall-mounting frame to the wall .................. 75
9.4 - Connect the radiator ................................................. 76
9.5 - Lock the radiator on its wall-mounting frame ......... 77
10 - Getting used ........................................................................ 77
10.1 - The control box ......................................................... 77
10.2 - Switching your radiator on/off ................................ 78
10.3 - Switch the screen on ............................................... 78
10.4 - Temperature setting ................................................. 78
10.5 - Set the day and time ............................................... 79
10.6 - Set the language ...................................................... 80
10.7 - Practical functions ................................................... 81
11 - The heating modes - When do you use them ? ....... 83
11.1 - Comfort mode .......................................................... 83
11.2 - ECO mode ............................................................... 85
11.3 - The Frost Free mode .............................................. 85
12 - Programming your radiator ............................................. 87
12.1 - Prog mode ................................................................ 87
13 - If you have a consumption reducer .............................. 89
14 - Maintenance ....................................................................... 89
15 - If a problem occurs ........................................................... 89
16 - Appendix .............................................................................. 91
16.1 - Warning ..................................................................... 91
16.2 - Identification of the radiator ................................... 91
Thank you for having chosen this equipment and having shown condence in our
products. The radiator that you have just purchased has passed many tests and inspections
to optimise its quality and provide you with full satisfaction.
Some recommendations:
Read the instructions before starting the installation of your radiator to satisfy standard
requirements.
Check the power supply voltage and switch the power supply off before connecting your
radiator.
Keep the instructions, even after you have installed your radiator.
Radiator characteristics:
CAT C : Equipment satisfying the NF Electricity performance standard according to
the criteria of the stated category.
IP24 : Equipment protected against water splashes
Classe II : Double insulation (no connection to earth).
IK08 : Resistance to mechanical shocks
: Equipment conforming with European Directive 2002/96/CE (DEEE).
1 - INSTALLING THE RADIATOR
1.1 - Radiator composition
Horizontal model Vertical model
Facade
Heating element
Thermostat
Wall-mounting
frame
Control box
Facade
Heating element
Thermostat
Wall-mounting
frame
Control box
1.2 - Installing your radiator
Your radiator is delivered with its wall-mounting frame. The choice of screws and inserts will
depend on the nature of your wall and you must make sure that you are using appropriate
screws and inserts capable of supporting the weight of the radiator.
This radiator was designed so that it will remain upright for the time necessary to make the
connections and install the wall-mounting frame, to facilitate the connection.
Once the radiator has been placed upright, you can remove the wall-mounting frame which
will be useful to you as a template to drill the holes.
Equateur2_1880-1585_interieur.indd 49 18/06/12 06:21
