ThyssenKrupp Flow2 User Manual

Controls
Flow2 stairlift
22
2.2.5 Standing up and folding up the seat
If your stairlift is equipped with a manual or automatic swivel seat, you can
stand up easily and safely by first turning the seat in the required direction
(see § 2.2.3).
1. Unfasten the safety belt (fig. 2/19).
2. If you want to remove the joystick, push it forwards (fig. 2/20).
3. Fold up the armrests (fig. 2/21).
4. Fold up the footplate by pulling the handle on the frame upwards (fig.
2/22).
5. Stand up and step off the seat (fig. 2/23).
6. Fold up the seat by pulling it upwards (fig. 2/24).

ThyssenKrupp Flow2 Specifications

General

Weight capacity	125 kg
Drive	Rack and pinion
Power supply	Rechargeable battery
Maximum Weight Capacity	125 kg
Speed	0.15 m/s
Foldable Arms	Yes
Foldable Footrest	Yes
Safety Belt	Yes
Control Type	Joystick or remote control
Battery Backup	Yes
Noise Level	Low
Seat Rotation	Powered
Track Type	Single tube
Seat Type	Padded seat
