TOHATSU M 2.5A2 User Manual

14
3
PARTS NAME
ENOM01301-0
2.5A2, 3.5A2, 3.5B2
1
2
3
9
10
20
21
18
17
16
15
12
14
13
22
11
24
19
4
5
7
8
23
25
27
26
28
30
29
6
ENOF02002-0
1 Air Vent Screw
2 Fuel Tank Cap
3 Top Cowl
4 Plug Cap Cover
5 Fuel Cock
6 Cooling Warter Check Port
7 Clamp Bracket
8 Drive Shaft housing
9 Propeller
10 Water Inlet (2.5/3.5A2)
11 Starter Handle
12 Shift Lever(3.5B2 only)
13 Handle Grip
14 Carring Handle
15 Clamp Screw
16 Thrust Rod
17 Oil Plug (Upper)
18 Anti-Ventilation Plate
19 Water Inlet (3.5B2 only)
20 Gear Case
21 Oil Plug (Lower)
22 Throttle Lever
23 Tilt Stopper
24 Stop Switch
25 Carburetor Cover
26 Chork Lever
27 Drive Shaft Housing
Grommet (3.5B2 only)
28 Steering Adjustment Screw
29 Spark Plug
30 Fuel Filter
