TOHATSU MFS 15 Service Manual

5
4st 9.9/15/20 2009
Power Tilt
P/L Fig. 21
15 N·m (1.1 lb·ft) [1.5 kgf·m]
5.2 N·m (4 lb·ft) [0.55 kgf·m]
1CapAss'y11-
1-1O-Ring11-
2ManualValveAss'y11-
2-1O-Ring,2.4-9.811-
2-2O-Ring11-
3C-Ring11-
4SealWasher11-
5ReliefValveAss'y11-
5-1O-Ring11-
6ValveAss'y11-
6-1O-Ring,1.5-3.511-
7O-Ring22-
8Pump11-
9Bolt22-
10 Bolt11-
11 Filter11-
12 PumpCoupling11-
Ref.
No.
Description
Remarks
Q'ty
9.9 15 20
13 O-Ring,2-62.511-
14 Band11-
15 Screw11-
16 Bolt22-
17 MotorBracketAss'y11-
17-1 Breaker11-
17-2 BreakerHolder11-
17-3 O-Ring11-
17-4 Brush11-
17-5 BrushSpring22-
17-6 Screw33-
17-7 BrushHolder11-
17-8 OilSeal11-
18 ArmatureAss'y11-
19 YokeAss'y11-
20 Screw22-
Ref.
No.
Description
Remarks
Q'ty
9.9 15 20
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
